Market · Southeast Asia
Yujing Entrance Door for Southeast Asia
The Yujing French & Modern Double Entrance Doors is configured here for Southeast Asia. The figures below are the published catalogue specification of the series; the market section covers what projects in Southeast Asia add to it. Send the opening schedule and the glazing you want, and the quotation comes back with the dimensional pack.
Yujing French & Modern Double Entrance Doors · Southeast Asia
Yujing French & Modern Double Entrance Doors
The double-leaf entrance line: a French panelled leaf and a modern flush or grooved leaf, on one sealed swing frame. The complete configuration, glass options and finish list are on the door series page.
- Opening
- Double-leaf swing, French or modern leaf
- Door style
- French panelled leaf · modern flush or grooved leaf
- Frame
- Aluminium with thermal-break profiles
- Structural build
- Aviation-grade aluminium plate · 1.0 mm steel plate · B1 flame-retardant board · PA66 insulation strip · automotive-grade sealing strip · aluminium backboard
- Glazing
- Tempered glass · grille-bar and panelled options
- Sidelights
- Matched fixed sidelights where the wall allows
- Performance (catalogue ratings)
- Sound 5 · thermal 8 · water 8 · air 8 · wind 9
- Hardware
- L8 face lock (palmar-vein option) · N6 fingerprint lock · F3 to F6 embedded locks · H3 horizontal handle
- Finishes
- Confirmed against the catalogue and samples on request
Engineering
French and modern leaf facesThe catalogue prints the series as two families, a French double leaf with raised panels and a modern double leaf with a flush or grooved face, and both run on the same double-swing frame.
Sealed double-leaf assemblyThe pair meets on a central stile and seats on an automotive-grade sealing strip, the part the catalogue ties to its sound, thermal, water and air ratings.
Thermal-break aluminium frameThe leaf is built on an aluminium frame with thermal-break profiles and PA66 insulation strips, the build the catalogue names across the entrance range.
Smart-lock readyThe catalogue hardware pages list the L8 face lock with an optional palmar-vein function, the N6 fingerprint lock and the F3 to F6 embedded locks, together with the H3 horizontal handle.
Heat, humidity and salt air
Southeast Asian sites push three things at aluminium: sustained heat, high humidity and, on the coast, salt spray. The finish carries the corrosion load, which is why fluorocarbon and powder lines are the standard shortlist for coastal work, with EPDM sealing and open self-cleaning drainage handling the moisture inside the section.
Glazing is specified per project: single glass where cooling load is the driver, insulating units where comfort is. The build-up comes back on the quotation against your climate and the budget line for the envelope.
Ports and logistics for the region
The main ports in the region are covered by standard export packing: modules travel upright, edge-protected, in 20 ft or 40 ft containers, and the loading plan for your opening mix ships with the quotation.
Transit times vary by origin port and destination, so they are confirmed per shipment rather than quoted from a fixed table.
Reference projects in comparable climates
apartment · day scene
Two-storey apartment duplex
Two-storey apartment duplex at dusk, street and rear elevations.
villa · day scene
Coastal villa, pool terrace
Coastal villa with a pool terrace, white volumes and a double garage front.
villa · day scene
Tropical house, deep roof overhang
Deep roof overhangs shade the sliding doors and keep the terrace usable through the wet season.
FAQ
Frequently asked
Which finishes hold up in coastal Southeast Asia?
Fluorocarbon and anodised lines are the standard shortlist against salt spray. RAL matching and two-tone exterior/interior combinations are available on request.
Do you ship to the Philippines and Malaysia?
Yes. Modules ship to ports across the region in export-standard containers, and the loading plan with the transit confirmation comes with the quotation.
What is the Yujing double entrance door?
It is the double-leaf entrance line of the AURORA range, printed on catalogue pages 063 to 067 as a French panelled leaf and a modern flush or grooved leaf on one double-swing frame.
What performance does the catalogue give?
Five catalogue ratings: sound insulation level 5, thermal insulation level 8, water tightness level 8, air tightness level 8 and wind-pressure resistance level 9, taken as printed for the sealed assembly.
Keep going
Series, market and range
Send your opening schedule
Series, glazing and finish come back as one quotation for Southeast Asia, with the full dimensional pack on PDF and CAD on request.
